PHF-M1820P2-DS1279

M18

 Anti-strong magnetic interference: innovative MVDC multi-variable dynamic compensation digital processing technology with high level of EMC characteristics and superior resistance to magnetic field interference

 Anti-weld slag splash: Teflon coating and all-metal products can easily cope with the impact of metal debris and high-temperature welding slag splash, suitable for harsh production environments such as the automotive industry.

 The attenuation coefficient is 1: effectively solves the influence of the detection distance attenuation caused by harsh environment.

Industry application:Automobile industry / Packaging industry / Smart storage / Metallurgical Industry / Petrochemical / Printing industry / Machine tool industry / Textile industry / Food Industry / Factory automation

主要特點

  • Operating voltage(vdc)
  • 10…30VDC
  • Voltage Drop Vd
  • <2.0VDC
  • Load Current
  • 200mA
  • NO Load Curren
  • <10mA(24V)
  • Swithing Hysteresis
  • <15%(sr)
  • Repeat Accuracy
  • <1.0%(sr)
  • Operating Temp
  • -25℃…70℃
  • Protection Class
  • IP67
  • Short Circuit Protection
  • YES
  • Reverse Polarity Protection
  • YES
  • Housing Material
  • Copper-plated Teflon
  • Material (Sensing Face)
  • PTFE
  • Output Indicator
  • LED Yellow

產品尺寸圖

下載
